State machines

A state machine makes a dotLottie animation interactive: it decides which part plays, in response to clicks, hovers and inputs. Lumetrope edits dotLottie 2.0 state machines in a node graph with a live preview.

Click or tap the animation, or focus it and press Enter, and watch the current state change.Current state: loading

What is in a state machine?

  • States: playback states that play a segment or the whole animation, and global states.
  • Transitions: instant or tweened, with guards.
  • Guards: conditions on numeric, string, boolean or event inputs, including $input references.
  • Inputs: the values the outside world sets. See Inputs and interactions.
  • Actions: every dotLottie action type.

How do I build one?

  1. Switch to the State Machine view.
  2. Add states and connect them with transitions.
  3. Add inputs and an interaction (for example, pointer enter) that sets one.
  4. Add a guard to the transition, such as "hover is true".

How do I test it?

Use the live preview: click the real animation, drive inputs by hand and watch the event log. In the full-screen player (F), the state machine is clickable too.
